Option Explicit
Private DevHandle As Long
Private InData(0 To 511) As Byte
Private Inited As Boolean
Public MinHeight As Long, MinWidth As Long
Private Type WaveFormatEx
FormatTag As Integer
Channels As Integer
SamplesPerSec As Long
AvgBytesPerSec As Long
BlockAlign As Integer
BitsPerSample As Integer
ExtraDataSize As Integer
End Type
Private Type WaveHdr
lpData As Long
dwBufferLength As Long
dwBytesRecorded As Long
dwUser As Long
dwFlags As Long
dwLoops As Long
lpNext As Long 'wavehdr_tag
Reserved As Long
End Type
Private Type WaveInCaps
ManufacturerID As Integer 'wMid
ProductID As Integer 'wPid
DriverVersion As Long 'MMVERSIONS vDriverVersion
ProductName(1 To 32) As Byte 'szPname[MAXPNAMELEN]
Formats As Long
Channels As Integer
Reserved As Integer
End Type
Private Const WAVE_INVALIDFORMAT = &H0& '/* invalid format */
Private Const WAVE_FORMAT_1M08 = &H1& '/* 11.025 kHz, Mono, 8-bit
Private Const WAVE_FORMAT_1S08 = &H2& '/* 11.025 kHz, Stereo, 8-bit
Private Const WAVE_FORMAT_1M16 = &H4& '/* 11.025 kHz, Mono, 16-bit
Private Const WAVE_FORMAT_1S16 = &H8& '/* 11.025 kHz, Stereo, 16-bit
Private Const WAVE_FORMAT_2M08 = &H10& '/* 22.05 kHz, Mono, 8-bit
Private Const WAVE_FORMAT_2S08 = &H20& '/* 22.05 kHz, Stereo, 8-bit
Private Const WAVE_FORMAT_2M16 = &H40& '/* 22.05 kHz, Mono, 16-bit
Private Const WAVE_FORMAT_2S16 = &H80& '/* 22.05 kHz, Stereo, 16-bit
Private Const WAVE_FORMAT_4M08 = &H100& '/* 44.1 kHz, Mono, 8-bit
Private Const WAVE_FORMAT_4S08 = &H200& '/* 44.1 kHz, Stereo, 8-bit
Private Const WAVE_FORMAT_4M16 = &H400& '/* 44.1 kHz, Mono, 16-bit
Private Const WAVE_FORMAT_4S16 = &H800& '/* 44.1 kHz, Stereo, 16-bit
Private Const WAVE_FORMAT_PCM = 1
Private Const WHDR_DONE = &H1& '/* done bit */
Private Const WHDR_PREPARED = &H2& '/* set if this header has been prepared */
Private Const WHDR_BEGINLOOP = &H4& '/* loop start block */
Private Const WHDR_ENDLOOP = &H8& '/* loop end block */
Private Const WHDR_INQUEUE = &H10& '/* reserved for driver */
Private Const WIM_OPEN = &H3BE
Private Const WIM_CLOSE = &H3BF
Private Const WIM_DATA = &H3C0
Private Declare Function waveInAddBuffer Lib "winmm" (ByVal InputDeviceHandle As Long, ByVal WaveHdrPointer As Long, ByVal WaveHdrStructSize As Long) As Long
Private Declare Function waveInPrepareHeader Lib "winmm" (ByVal InputDeviceHandle As Long, ByVal WaveHdrPointer As Long, ByVal WaveHdrStructSize As Long) As Long
Private Declare Function waveInUnprepareHeader Lib "winmm" (ByVal InputDeviceHandle As Long, ByVal WaveHdrPointer As Long, ByVal WaveHdrStructSize As Long) As Long
Private Declare Function waveInGetNumDevs Lib "winmm" () As Long
Private Declare Function waveInGetDevCaps Lib "winmm" Alias "waveInGetDevCapsA" (ByVal uDeviceID As Long, ByVal WaveInCapsPointer As Long, ByVal WaveInCapsStructSize As Long) As Long
Private Declare Function waveInOpen Lib "winmm" (WaveDeviceInputHandle As Long, ByVal WhichDevice As Long, ByVal WaveFormatExPointer As Long, ByVal CallBack As Long, ByVal CallBackInstance As Long, ByVal Flags As Long) As Long
Private Declare Function waveInClose Lib "winmm" (ByVal WaveDeviceInputHandle As Long) As Long
Private Declare Function waveInStart Lib "winmm" (ByVal WaveDeviceInputHandle As Long) As Long
Private Declare Function waveInReset Lib "winmm" (ByVal WaveDeviceInputHandle As Long) As Long
Private Declare Function waveInStop Lib "winmm" (ByVal WaveDeviceInputHandle As Long) As Long
Sub InitDevices()
Dim Caps As WaveInCaps, Which As Long
DevicesBox.Clear
For Which = 0 To waveInGetNumDevs - 1
Call waveInGetDevCaps(Which, VarPtr(Caps), Len(Caps))
'If Caps.Formats And WAVE_FORMAT_1M08 Then
If Caps.Formats And WAVE_FORMAT_1S08 Then 'Now is 1S08 -- Check for devices that can do stereo 8-bit 11kHz
Call DevicesBox.AddItem(StrConv(Caps.ProductName, vbUnicode), Which)
End If
Next
If DevicesBox.ListCount = 0 Then
MsgBox "You have no audio input devices!", vbCritical, "Ack!"
End
End If
DevicesBox.ListIndex = 0
End Sub
Private Sub Check1_Click()
Scope(0).Cls
Scope(1).Cls
If Check1.Value = vbChecked Then
Scope(0).AutoRedraw = True
Scope(1).AutoRedraw = True
Else
Scope(0).AutoRedraw = False
Scope(1).AutoRedraw = False
End If
End Sub
Private Sub Command1_Click()
Static WaveFormat As WaveFormatEx
With WaveFormat
.FormatTag = WAVE_FORMAT_PCM
.Channels = 2 'Two channels -- left and right
.SamplesPerSec = 11025 '11khz
.BitsPerSample = 8
.BlockAlign = (.Channels * .BitsPerSample) \ 8
.AvgBytesPerSec = .BlockAlign * .SamplesPerSec
.ExtraDataSize = 0
End With
Debug.Print "waveInOpen:"; waveInOpen(DevHandle, DevicesBox.ListIndex, VarPtr(WaveFormat), 0, 0, 0)
If DevHandle = 0 Then
Call MsgBox("Wave input device didn't open!", vbExclamation, "Ack!")
Exit Sub
End If
Debug.Print " "; DevHandle
Call waveInStart(DevHandle)
Inited = True
Command2.Enabled = True
Command1.Enabled = False
Call Visualize
End Sub
Private Sub Command2_Click()
Call DoStop
End Sub
Private Sub Form_Activate()
Slider1.Value = 0
Slider2.Value = 0
End Sub
Private Sub Form_Load()
Call InitDevices
'Set MinWidth and MinHeight based on Shape...
Dim XAdjust As Long, YAdjust As Long
XAdjust = Me.Width \ Screen.TwipsPerPixelX - Me.ScaleWidth
YAdjust = Me.Height \ Screen.TwipsPerPixelY - Me.ScaleHeight
'MinWidth = Shape.Width + XAdjust
' MinHeight = Shape.Height + YAdjust
Scope(0).ScaleHeight = 256
Scope(0).ScaleWidth = 255
Scope(1).ScaleHeight = 256
Scope(1).ScaleWidth = 255
' Shape.BackStyle = vbTransparent
'Set the window proceedure to my own (which restricts the
'minimum size of the form...
'Comment out the SetWindowLong line if you're working with it
'in the development environment since it'll hang in stop mode.
MinMaxProc.Proc = GetWindowLong(Me.HWnd, GWL_WNDPROC)
SetWindowLong Me.HWnd, GWL_WNDPROC, AddressOf WindowProc
End Sub
Private Sub Form_Unload(Cancel As Integer)
If DevHandle <> 0 Then
Call DoStop
End If
End Sub
Private Sub DoStop()
Call waveInReset(DevHandle)
Call waveInClose(DevHandle)
DevHandle = 0
Command2.Enabled = False
Command1.Enabled = True
Slider1.Value = 0
Slider2.Value = 0
End Sub
Private Sub Visualize()
Static Wave As WaveHdr
Wave.lpData = VarPtr(InData(0))
Wave.dwBufferLength = 512 'This is now 512 so there's still 256 samples per channel
Wave.dwFlags = 0
Do
Call waveInPrepareHeader(DevHandle, VarPtr(Wave), Len(Wave))
Call waveInAddBuffer(DevHandle, VarPtr(Wave), Len(Wave))
Do
'Nothing -- we're waiting for the audio driver to mark
'this wave chunk as done.
Loop Until ((Wave.dwFlags And WHDR_DONE) = WHDR_DONE) Or DevHandle = 0
Call waveInUnprepareHeader(DevHandle, VarPtr(Wave), Len(Wave))
If DevHandle = 0 Then
'The device has closed...
Exit Do
End If
Scope(0).Cls
Scope(1).Cls
Call DrawData
DoEvents
Loop While DevHandle <> 0 'While the audio device is open
End Sub
Private Sub DrawData()
Static x As Long
Dim L, R As Integer
Scope(0).CurrentX = -1
Scope(0).CurrentY = Scope(0).ScaleHeight \ 2
Scope(1).CurrentX = -1
Scope(1).CurrentY = Scope(0).ScaleHeight \ 2
'Plot the data...
For x = 0 To 255
Scope(0).Line Step(0, 0)-(x, InData(x * 2))
Scope(1).Line Step(0, 0)-(x, InData(x * 2 + 1)) 'For a good soundcard...
'Use these to plot dots instead of lines...
'Scope(0).PSet (X, InData(X * 2))
'Scope(1).PSet (X, InData(X * 2 + 1)) 'For a good soundcard...
'My soundcard is pretty cheap... the right is
'noticably less loud than the left... so I add five to it.
'Scope(1).Line Step(0, 0)-(X, InData(X * 2 + 1) + 5)
Next
'pengaturam multi warna
If (Scope(0).CurrentY) < 100 Then Scope(0).ForeColor = &HFF00&
If (Scope(0).CurrentY) > 100 And (Scope(0).CurrentY) <= 120 Then Scope(0).ForeColor = &HFFFF&
If (Scope(0).CurrentY) > 121 And (Scope(0).CurrentY) <= 200 Then Scope(0).ForeColor = &HFFFF00
If (Scope(0).CurrentY) > 200 Then Scope(0).ForeColor = &HFF00FF
Indikator(0).BackColor = (Scope(0).ForeColor)
